B300SND Signalling Horn
The B300SND is a compact signalling horn suitable for mounting on machinery or in general signalling applications. The B300SND reproduces the alert sound of traditional electro-mechanical equivalents but without any of the reliability issues. In addition to the "buzzer" type sound the unit features a further two alarm sounds.
The B300SND is a component of the Spectra range and can be configured with the B350 or B450 traffic light beacons for complete audio-visual signalling.
PRODUCT SPECIFICATIONS:
Number of tones: 3
Output: 98 dB(A) @ 1m
Mounting: Surface mount (wall bracket available)
Entries: 1 x 5-7mm push through grommet
1 x M20 cable entry
Dimensions: ø100 x 103mm
Ingress protection: IP65
Housing material: High impact UL94 VO (f1) PC
Terminals: 0.5 to 1.5mm2
Operating temp.: -25 to +50¤C
Storage temp.: -40 to +70¤C
Relative humidity: 90% at 20¤C
FEATURES:
- Bayonet fixing body.
- Anti-tamper locking screw.
- Stainless steel fixings.
- Compatible with B350 and B450 traffic light series
