BExH120 'Hootronic' Flameproof Sounder
The flameproof BExH120 ‘Hootronic’ Siren is suitable for Zone 1 & 2 applications. The BExH120D authentically reproduces the traditional sounds of electro-mechanical devices whilst providing a significantly higher level of performance and reliability. The BExDH120 variant is also suitable for Zone 21 & 22.
Sound level outputs are up to 117.5dB(A) at 1 metre with a choice of 5 alarm sounds combining the signalling power of multiple electro-mechanical products in one unit.
1. Industrial Hooter
2. High Frequency Mechanical Siren
3. Medium Frequency Mechanical Siren
4. Electro Mechanical Buzzer
5. Mechanical Bell
Features:
* Very large termination area
* Ratchet adjustable stainless steel ‘U’ bracket
Approvals:
ATEX certificate:
KEMA 00ATEX6312
EN 60079-0 : 2006
EN 60079-1 : 2007
EN 61241-0 : 2006
EN 61241-1 : 2004
IECEx certificate:
IECEx KEM 10.0003
IEC 60079-0 : 2004 (Ed4)
IEC 60079-1 : 2007 (Ed6)
IEC 61241-0 : 2004 (Ed1)
IEC 61241-1 : 2004 (Ed1)
Safety-integrity suitability: SIL1
Inmetro certificate: 10-IEx-0009
Nominal Output: 117.5dB(A) @ 1m +/- 3dB - Tone 4
Number of Tones: 5
Number of Stages: 3
Volume Control: Yes
Effective Range: 200m @ 1KHz
Voltages DC: 24V dc
Voltages AC: 115V ac, 230V ac
Housing Material: Marine grade copper free LM6 Aluminium
Housing Finish: Phosphated & powder coated finish: anti-corrosion
Colour: RAL3000 Red or RAL7038 Grey (others available on request)
