Technical data
Standards: IEC 60947-5-1 / EN 60947-5-1 EN 60204-1
Enclosure: aluminium die-cast, enamel finish
Degree of protection: IP 65 nach EN 60529
Contact material: silver
Switching elements: Micro switch change-over contact with single break
Temperatur range: -20° C to +80° C
Connection: AMP Blade terminal 2,8 x 0,5
Operation: Plunger with steel ball
Mounting distance: 27 mm - M4
Cable entry: M16 x 1,5
Electrical design: IEC 60947-5-1, electrically isolated from each other elements
Electrical load: 250 V AC 5 A (AC-15)
230 V DC 0,2 A (DC-13)
Minimum load: 24 V AC/DC 10 mA
Short circuit protection: 5 A (träge)
Mechanical life:> 1 million operations
Switching frequency: max. 1800 operations / h
