Mini TwinLIGHT 24VAC/DC RED
The quick and easy way to create the perfect signalling solution.
NB: Please include the suitable mounting adapter for the product which can be found in the tab accessories.
| Part No.: | 260.210.75 |
| Voltage: | 24V AC/DC |
| Signal effect: | TwinLight |
| Light colour: | Green |
| | |
| Mechanical data: | |
| Height: | 85 mm |
| Diameter: | 62 mm |
| Materials: | PC PC/ABS |
| Housing colour: | Grey |
| Protection category: | IP66 |
| Connection: | Push-in terminal |
| Cross-sectional area minimum: | 0,25mm² / 24AWG |
| Cross-sectional area maximum: | 1,50mm² / 16AWG |
| Working temperature minimum: | -30°C |
| Working temperature maximum: | +60°C |
| UL Type Rating: | Type 12 |
| Weight with packaging: | 92 g |
| Product weight: | 71 g |
| | |
| Electrical data: | |
| Operating voltage: | 24V |
| Operating voltage type: | AC/DC |
| Operating voltage frequency: | 50Hz |
| Operating voltage tolerance: | +/- 10% |
| Rated operational voltage: | 24 VDC |
| Rated operational current: | 72 mA |
| Rated inrush current:: | 1600 mA |
| Protection class Protection: | Class 2 |
| Pollution degree: | 3 |
| Overvoltage category: | I |
| | |
| Optical data: | |
| Light source: | LED |
| Light colour: | Yellow |
| Optical signal image: | TwinLight |
| Blink frequency:: | 1 Hz |
| Service life optical:: | 50,000 h minimum |
| |
