Mini Bracket Cable Gland [grey]
EvoSIGNAL is the new modular, simple and clear standard solution for the signaling sector.
| Part No.: | 260.700.06 |
| | |
| Mechanical data: | |
| Length: | 67 mm |
| Width: | 62 mm |
| Height: | 51 mm |
| Diameter: | 62 mm |
| Materials: | PC/ABS |
| Housing colour: | Grey |
| Protection category: | IP66 |
| Cable entry: | Screwed cable gland |
| Cable entry minimum: | d = 8 mm |
| Cable entry maximum: | d = 12 mm |
| Tension relief Present: | (conforms to VDI) |
| Type of fixing: | Wall mounting |
| Working temperature minimum: | -30°C |
| Working temperature maximum: | +60°C |
| Weight with packaging: | 39 g |
| Product weight: | 35 g |
| |
